Compression Tester
Compression Tester for Packaging Bags
1 / 2Compression Tester
The TS-CT2 Compression Tester is engineered to evaluate the compression resistance and burst strength of a wide variety of packaging bags.
Key Specifications
Pressure Range
50–700 kPa
Pressure Accuracy
±0.8%
Test Distance
0–100 mm
Compression Surface Size
280 × 180 mm
Global Shipping
50+ countries
2-Year Warranty
Parts & service
Expert Support
Dedicated team
Have a question about this instrument?
Talk to an expertProduct Information
The TS-CT2 Compression Tester is engineered to evaluate the compression resistance and burst strength of a wide variety of packaging bags. It supports quality inspection, drug testing, and scientific research, and is widely applied across the packaging, film, food, pharmaceutical, and daily chemical industries, among others.
Key Features
Advanced Configuration and Technology
- Pneumatic pressure loading for easy operation and a simple test procedure.
- Set the required pressure value, and the instrument maintains it throughout the compression test.
- Pressure can be adjusted while compression is in progress.
- LCD screen displays test parameters in real time.
Technical Parameters
| Parameter | Specification |
| Pressure range | 50~700 Kpa |
| Air Pressure range | 0-0.7 MPa |
| Pressure accuracy | ±0.8% |
| Test distance | 0～100mm |
| Compression surface size | 280×180mm |
| Air connection | Φ6mm Air pipe |
| Test Disc | 1 |
| Dimensions | 394×355×505mm |
| Weight | 21kg |
| Power | 100W |
| Power supply | AC 220V，50Hz |
Applications
- Pressure resistance — It is suitable for pressure resistance testing of various packaging bags.
- Burst resistance — It is suitable for burst strength testing of various packaging bags.
