Digital Thickness Tester
Digital Thickness Tester for Plastic Films, Paper & Sheet Materials
1 / 2Digital Thickness Tester
The TS-DTG Digital Thickness Tester is a high-precision instrument designed for accurate and repeatable thickness measurement of plastic films, sheets, paper, cardboard, metal sheets, silicon wafers, and other materials.
Key Specifications
Test Range
0–6 mm
Test Resolution
0.1 µm
Measurement Points
1–30 Points
Measuring Force
0.7 N
Global Shipping
50+ countries
2-Year Warranty
Parts & service
Expert Support
Dedicated team
Have a question about this instrument?
Talk to an expertProduct Information
The TS-DTG Digital Thickness Gauge is a high-precision instrument engineered to meet international standard requirements and evolving market demands, including GB and ASTM specifications. By integrating optical, mechanical, electrical, and computational technologies within a single system, the instrument delivers accurate and repeatable measurement performance while remaining simple to operate. It features a digital display and can be connected to a computer for automated data control.
The gauge is primarily intended for thickness measurement and comparative analysis of plastic films, paper, and a range of other materials.
Key Features
- Delivers precise and reliable measurement performance, with a resolution of up to 0.1 µm.
- Offers both manual and automatic measurement modes, supporting single-point or multi-point testing as required.
- Allows the automatic sampling interval and the number of measurement points to be configured by the user.
- Features an LCD display and enables test results to be printed through a connected microcomputer.
Technical Parameters
| Parameter | Specification |
| Test range | 0~6 mm |
| Test resolution | 0.1 µm |
| Injection distance | 0~500 mm |
| Measurement points | 1~30 points |
| Measuring force | 0.7 N |
| Measuring head | Φ6 mm |
| Power supply | AC 220 V, 50 Hz |
| Dimensions | 410 mm×310 mm×340 mm |
| Power | 100 W |
| Weight | 19.5 kg |
Applications
Plastic Film & Sheet
Suitable for thickness measurement of a wide range of plastic films, sheets, and diaphragms.
Paper & Cardboard
Applicable to thickness measurement of paper, cardboard, and composite cardboard materials.
Metal Sheet & Silicon Chip
Used for thickness measurement of silicon wafers, metal foils, and various metal sheets.
Corrugated Cardboard
Enables reliable thickness determination of corrugated cardboard.
