Electronic Tensile Tester
Electronic Tensile Tester for Packaging and Material Testing
1 / 2Electronic Tensile Tester
The TS-ET1 is a single-column electronic tensile testing machine designed for accurate evaluation of the mechanical properties of plastic films, flexible packaging materials, paper, tapes, medical patches, and other metallic and non-metallic materials.
Key Specifications
Force Range
0 – 300 N
Test Speed
0 – 500 mm/min
Force Accuracy
±1% FS
Sampling Rate
100 times/s
Global Shipping
50+ countries
2-Year Warranty
Parts & service
Expert Support
Dedicated team
Have a question about this instrument?
Talk to an expertProduct Information
The TS-ET1 is a single-column electronic tensile testing machine engineered for accurate evaluation of the mechanical properties of a wide range of materials. Developed in accordance with ASTM and other applicable standard requirements, the instrument combines high-precision force sensors with stable, dependable loading to deliver reliable measurement results and a long operating life. Its LCD screen runs dedicated testing software that displays the test curve in real time and stores test reports for later retrieval, allowing testing to be carried out quickly and conveniently.
Operation is fully automated through a dedicated control and measurement unit, supported by comprehensive safety functions including limit protection, overload protection, and an emergency stop.
The TS-ET1 is suitable for mechanical property tests such as tension, peeling, heat sealing, tearing, and puncture testing of a broad range of metallic and non-metallic materials, and it meets the testing requirements set by national technical supervision authorities. It is widely used by manufacturers in the plastic film, food, and pharmaceutical packaging sectors for product quality control, as well as by testing institutions and by schools and research organizations for scientific and teaching purposes.
Key Features
Elegant and space-efficient design
- Desktop column structure that is compact and visually refined, allowing comfortable seated operation.
Flexible and efficient testing methods
- Performs tension, peeling, heat-sealing, tearing, puncture and other tests, with adjustable settings for width, speed, thickness, and clamping distance.
- High sampling rate of 100 times per second for accurate, reliable test data.
Safe, high-end mechanical structure
- Three-level safety protection with an emergency stop switch for guaranteed operating safety.
- Imported core components provide high precision and an extended service life.
- LCD display shows real-time test data and machine status.
Intelligent operating system
- Supports user management, permission management, and audit trail functions, in line with the requirements of GMP Appendix “Computerized System.”
Technical Parameters
| Parameter | Specification |
| Force measurement range | 0~300 N (optional 0~500 N), 1250% elongation |
| Force measurement accuracy | Indication within ±1% FS (level 1) |
| Test speed | 0~500 mm/min (Infinitely variable speed) |
| Displacement accuracy | Indication within ±1% |
| Effective test width | 30 mm（50mm customizable) |
| Effective test stroke | 750 mm（1000mm customizable） |
| Size | L×W×H：600 mm×500 mm×1300 mm |
| Weight | 65 kg |
| Power supply | AC 220 V, 50 Hz |
Applications
Plastic film: Suitable for tensile, peeling, heat-sealing, tearing and other performance tests of plastic films, composite materials, soft packaging materials, tapes and similar products.
Composite film bag: Suitable for tensile, peeling, heat-sealing, tearing and other performance tests of composite films, co-extruded films, composite bags, retort pouches, aluminum-plastic composite bags and similar products.
Paper: Suitable for tensile, peeling, heat-sealing, tearing and other performance tests of paper, kraft paper, facial tissue, toilet paper and similar products.
Medical patch: Suitable for tensile, peeling, heat-sealing, tearing and other performance tests of medical cold compresses, plasters and similar products.
