Heat Shrink Tester
Controlled Temperature Heat Shrinkage Testing Instrument
1 / 2TS-HST1
Heat Shrink Tester
The TS-HST1 Heat Shrink Tester evaluates the heat shrinkage performance of plastic films and heat-shrinkable materials under controlled temperature conditions, providing reliable testing for quality control, material evaluation, and research and development applications.
Key Specifications
Temperature Range
RT – 250°C
Temperature Accuracy
±0.1°C
Sample Size
≤140 × 140 mm
Power
1100 W
Heat Shrink TesterHeat Shrinkage TestingPlastic Film TestingPackaging Testing
Global Shipping
50+ countries
2-Year Warranty
Parts & service
Expert Support
Dedicated team
Have a question about this instrument?
Talk to an expertProduct Information
The TS-HST1 Heat Shrink Tester is designed to evaluate the heat shrinkage performance of materials under controlled temperature conditions.
Key Features
- Constructed with a high-quality aluminum alloy liquid tank and cover, ensuring efficient heat conduction and reliable heat retention throughout the test cycle.
- Equipped with an LCD display for real-time temperature and timing readouts, enabling straightforward parameter setup and simplified, user-friendly operation.
Technical Parameters
| Parameter | Specification |
| Sample size | ≤140×140mm |
| Temperature range | Room temperature~250℃ |
| Temperature control accuracy | ±0.1℃ |
| Instrument size | 440×370×310mm |
| Weight | 16kg |
| Power | 1100W |
| Power supply | AC 220V，50Hz |
Applications
- Heat shrinkage testing of plastic films.
- Evaluation of heat shrinkage performance under controlled temperature conditions.
- Quality control of heat-shrinkable materials.
- Research and development testing of heat-shrinkable materials.
