Product Information

The TS-WT1 Wall Thickness Tester is a professional, high-precision instrument for measuring the wall thickness of ampoules, vials, infusion bottles, beer bottles and plastic bottles used in the food, medicine, cosmetics and many other industries. It offers two measuring functions, bottom thickness and sidewall thickness, and delivers a test resolution of up to 0.001 mm. The test height can be adjusted, so bottles of many different capacities can be accommodated. It measures a thickness range of 0 to 10 mm and is designed to test to ISO 8536-1:2006.

Key Features

1. Real-Time Touch Screen Display

The touch screen displays the measuring point position and thickness value in real time.

2. User Management

A dedicated user management function helps ensure data integrity and standardized operation.

3. Built-In Micro Printer

The built-in micro printer quickly prints each measurement result together with the statistical maximum, minimum and average values.

4. Data Storage

The instrument stores no fewer than 100 data sets, with 10 measuring results in each set.

5. Adjustable Test Space

The test space is adjustable, so the instrument suits a wide range of products.

6. ISP Online Upgrade

The system program supports ISP online upgrade, allowing personalized service.

7. High-Speed Processing Chip

The instrument is built around a high-speed processing chip.

Technical Parameters

Applications

The TS-WT1 Wall Thickness Tester is a professional instrument for testing ampoules, medicinal bottles, wine bottles, plastic bottles, PET bottles, PET bottle preforms and glass water cups. As a professional, high-precision bottle thickness testing instrument, it is widely used by quality inspection institutions, testing institutions, packaging material manufacturers, pharmaceutical companies, food companies and other organizations.
