Product Information

The TS-8172-B is a laboratory-scale internal mixer engineered for the blending of plastics, chemical raw materials, and a wide range of low-viscosity compounds. The instrument integrates a PLC-based control system with a color human-machine interface (HMI), allowing temperature, mixing time, and rotor speed to be monitored in real time throughout the process.

Once the operating parameters are configured, the mixing cycle runs fully automatically, offering a straightforward, energy-efficient, and highly repeatable workflow suited to laboratory and quality-control applications.

Key Features

PLC Programmable Color Touch Screen Control

PLC programmable color touch screen, man-machine interface operation system, all parameters such as temperature, time, and speed can be set and controlled arbitrarily, and the mixing process is dynamically displayed

Variable Rotor Speed Control

The rotor speed is controlled through a frequency converter, with a speed range of 0-50rpm frequency converter speed regulation.

Water-Cooled Shear-Type Mixing Shaft

The mixing shaft uses a shear type, hollow shaft with water cooling for controlled laboratory mixing operations.

Integrated Sealing and Dust Prevention

The system incorporates a stainless steel armored type sealed dust cover with built-in suction and exhaust channels, together with a wear-resistant and high-temperature-resistant rubber seal around the upper weight for dust prevention.

Technical Parameters

Applications

Plastic Material Mixing

Used for laboratory-scale blending of plastics and chemical raw materials.

Material Formulation Development

Suitable for laboratory research involving controlled mixing of different material formulations.

Plastic Compounding

Used for mixing plastic compounds under controlled temperature, time, and rotor speed conditions.

Quality-Control Testing

Suitable for repeatable laboratory mixing processes used in material evaluation and quality-control applications.
