Laboratory Compression Press Molding Machine

Name: Laboratory Compression Press Molding Machine
Brand: TestShine

1 / 2

TS-CMP30T

Laboratory Compression Press Molding Machine

Laboratory compression press molding machine designed for compression molding of thermosetting plastics, foamed plastics, rubber products, and foamed rubber materials with adjustable pressure, temperature, stroke, speed, and pressure-holding time.

Key Specifications

Pressure Capacity

30T

Temperature Range

Room temp. – 250°C

Cylinder Stroke

Max 150 mm

Cylinder Speed

11 mm/s

Compression MoldingPress MoldingRubber TestingPlastic Testing

Request a Quote Request Sample Testing

Global Shipping

50+ countries

2-Year Warranty

Parts & service

Expert Support

Dedicated team

Have a question about this instrument?

Talk to an expert

Product Introduction

The TS-CMP30T is a flat press designed as core equipment for compression molding a wide range of thermosetting plastics and foamed plastic materials. It is equally suited to vulcanizing rubber, including rubber mold and non-molded rubber products as well as foamed rubber materials. Each unit is built around a self-contained power pack and electrical system, operated through centralized push-button controls. Working pressure and heating temperature are both adjustable within defined ranges, and the press is available in manual or semi-automatic configurations to suit different production requirements.

Key Features

Built on a four-column, three-plate steel frame; the movable platen travels parallel to the working surface, and precision guide sleeves on all four columns keep motion accurate and repeatable.
Pressure, stroke, speed, and pressure-holding time are all adjustable to match specific pressing process requirements.
Upper and lower heating platens are temperature-controlled independently, using an RKC intelligent temperature controller with a control accuracy of ±1°C.

Technical Parameters

Model	TS-CMP30T
Pressure Capacity	30T
Pressure Gauge (control)	Dual-node pressure is adjustable, with a pressure adjustment precision of 10%.
Plate Size (mm)	250250/300300/350350/400400/450450/500500/600*600【mm】
Heating Platen Material	High-temperature-resistant imported steel plate; surface carburized and quenched, specially treated for fast heat conduction; maintains flatness under pressure without deformation; wear-resistant
Platen Hardness	50–60 HRC
Platen Flatness	0.03 mm
Platen Parallelism	≤0.16 mm
Temperature Range [choose one; subject to quotation]	Room temp. – 250°C [max. temperature customizable up to 500°C]
Temperature Uniformity	2.5°C [the larger the platen, the higher the temperature and the poorer the uniformity]
Temperature Controller	Precision module with PLC touchscreen control; numeric display on touchscreen
Temperature Control Method	Temperature control mainboard with precise control; auto-tuning with high-precision sensor; display accuracy: ±1.0°C
Timer	Set and displayed on touchscreen; time range 0.1 s – 99 min – 9.9 hr
Heater	Built-in cylindrical heating elements inside the mold [power configured according to platen area to ensure platen temperature uniformity; not a single fixed power]
Heating-up Time	From room temperature to 160°C: approx. 15 min
Heating Platens (two)	Each platen can be set and controlled to its own temperature
Heating Method	Electric heating
Cooling Method	Water cooling
Hydraulic System	Adopts CREE.6 closed-loop hydraulic flow control system; oil pump drives high-performance electro-hydraulic with high-precision frictionless cylinder piston for constant-rate control; features automatic pressure compensation. One-press automatic pressure replenishment, strong load capacity, smooth lift; automatic pressurizing, holding and releasing.
Cylinder Stroke	Max 150 mm [customizable]
Cylinder Speed	11 mm/s
Pressure Gauge	0–200 kg/cm²
Mold Opening Method	Fully automatic lift/lower (with manual/automatic dual function)
Safety Device	Safety guard, safety door
Number of Safety Devices	4
Matching Mold Frame [optional]	Custom
Main Machine Dimensions	(W×D×H) 1200×750×1650 mm
Power Supply	3-phase, AC 380 V
Machine Weight	≈ 680 kg
